Ultraviolet LED Strip

5 0 Reviews

Ultraviolet LED strip introduction: UV LED strip including UVA UVB UVC , we mainly supply all range UV strip light, wavelength from 360nm to 400nm

Availability:


Inquiry Download

Product Description

Ultraviolet LED strip introduction:

UV LED strip including UVA UVB UVC , we produce all range UV strip light, wavelength is from 305nm to 315nm and 360nm to 400nm .

Ultraviolet wavelength

Product parameters:

Model	Wavelength	LED Qty per meter	Power Consumption	Voltage	PCB Size
Model	Wavelength	LED Qty per meter	W/M	V/DC	mm
STSN-60UV2835	360~365nm	60	≤5W	12V/24V	Double Copper PCB 5000*10mm
STSN-120UV2835	360~365nm	120	≤10W	12V/24V	Double Copper PCB 5000*10mm
STSN-240UV2835	360~365nm	240	≤20W	12V/24V	Double Copper PCB 5000*10mm
STSN-30UV3535	305~315nm	30	≤8W	12V/24V	Double Copper PCB 5000*12mm
STSN-60UV3535	305~315nm	60	≤14.4W	12V/24V	Double Copper PCB 5000*12mm
STSN-120UV3535	305~315nm	120	≤20W	12V/24V	Double Copper PCB 5000*12mm
STSN-60UV5050	395nm-400nm	60	≤14.4W	12V/24V	Double Copper PCB 5000*10mm
STSN-120UV5050	395nm-400nm	120	≤20W	12V/24V	Double Copper PCB 5000*10mm

For more product information, please download the specifications.SMD2385-UVA-LED-strip.pdf

UV LED tape features:

1.Epistar SMD5050 or SMD2835 or SMD3535 TOP SMD LED as lighting resources, long life span and low Luminous Decay. All our LEDs can meet LM80 test standard, 70% at 50000 hours.

2.Can be cut by 3 LED (DC 12v high output led strip ) and 6 LED (DC 24v high output led strip )

3. Original 3M Brand 9495-200MP / 300LSE double-sided adhesive back tape as standard sticker .

4.High flexible PCB , high quality double layers PCB, at least 2 ounces, or 3 ounces in particular models. So there is low voltage drop and good heat dissipation too. .

5.IP20 non-waterproof or IP65 & IP68 with silicone gel

6.Waterproof Material: Silicone hollow tube ,Silicone glue and Silicone transparent waterproof connector

7.Single BIN LED selection to ensure color consistency

8.Ultraviolet wavelength ranges inclduing : 305nm ~ 315nm 360nm ~ 365nm 390 ~ 395nm 395~ 405nm

Ultraviolet uv led strip 305nm 365nm 400nm DC12v DC24v

Why Choose Real UV:

Ultraviolet rays have many applications, especially in the UVA region, which is generally considered to be between 315 and 400 nm.

Many UV LED products on the market today call the 405 nm-centered purple light advertising as "ultraviolet",but in fact this is ultraviolet radiation at the boundary between UV-A and visible violet light.

These applications depend on ultraviolet light sources that provide sufficient energy in this range, and are usually designed for maximum efficiency in the center of this range (about 360 nm). The result is that 405 nm light will produce insufficient energy and the desired UV effect.

UVA wavelength:

UVA wave length
