SMD2020 WS2812C Mini Flexible LED Pixel Display Panel

Dimension: 68mm*144mm, Pixels number: 16pixels×32pixels=512 pixels, WS2812C-2020 SMD leds.

Availability:

SMD2020 LED Matrix Display


SMD2020 LED Matrix Features:

1. Built-in 16x32pcs SMD2020 WS2812C IC, 512 RGB chips, each RGB chip is individually controlled.

2. SPI protocol, any controller that supports SPI protocol can control this flexible matrix display.

3. Data speed of WS2812 addressable flexible panel is 30fps,600k Hz, much quicker than other IC.

4. You can bend this product in installation but not too much.

5. Full color programmable with dimming feature.

6. These products are CE & RoHS certificated.


Mini Pixel Screen Parameters:

Product Name

 WS2812C Flexible LED Matrix

LED type

SMD2020 RGB LED

Led Quantity

512 LEDs/Pcs

Pixel Quantity

512pixels /Pcs

LED Power Consumption

52W

Input Voltage

DC5V

Pixel pitch

P2mm

Brightness/pc

1000-1500lm

Storage Temperature

-30°C ~ 80°C

Operating Temperature

-20°C ~ 60°C

IC chip

WS2812C full color

Average lifespan

50000 hours

Dimension

16X32cm

Waterproof rate

IP20/IP65

Warranty

5years


Six different ways to control the pixel panel:

connect way


Controll by K-1000C


Detail pictures of Mini WS2813C LED Panel

SMD2020 Matrix

WS2812C Matrix

-1


Pixel LED Matrix Panel Application

_202112151338332

_20211215133833


Installation the Flexible LED Display

_202112151338335

_202112151338333


Test addressable LED panels before shipping

_202112151338334

FAQ:

Q1: How to choose the LED screen suitable for my needs?

A1: When you choose a led screen, you only need to consider three simple questions.

      1. Will you use it indoors or outdoors?

      2. Is it for rental purposes (need to move from one place to another often) or for fixed installation (to be installed in one place forever)?

      3. What is the length and width of the LED screen you want to buy?


Q2: Which pixel pitch should I choose?

A2: There are many differences from 1.25--16mm pixel pitch, in principle, it is so-usually indoor LED screens use smaller pixels (1.25mm-10mm), outdoor LED use larger pixels (2.5mm-16mm) screens ( For example, huge highway ads).


Q3: Which control system should I choose?

A3: There are synchronous and asynchronous control systems on the market. For large-size LED screens (usually more than 20 square meters), you need to use an asynchronous control system; when it is less than 20 square meters, you can use synchronous or asynchronous. For asynchronous control systems, you can choose to use wifi, 3G, 4G, and other wireless control.


Q4: How to pay?

A5: We accept payment online via Alibaba, or offline to our company account via T / T, Paypal, or Western Union.


Q5: How to ship?

A6: This is optional, and we respect our customers' choices. You can choose to ship by air, DHL (FedEx, UPS, TNT, EMS, etc.) international express company, or by sea according to the weight, volume, and required delivery time of the goods.


Q6: How to install after receiving?

A7: We will provide you with drawings to guide you through the installation. We can also provide drawings of steel structures, software settings drawings, or photos, or send our engineers to help you when needed.
